Bosch 86cm Undermount Integrated Rangehood - Black (Series 8)
Model DLN88PC60A
IPN 868261
Bosch
$ PRICE MATCH GUARANTEE

We'll match* a local competitor's advertised price on the same product. Contact us for details!

Warranty
  • Bosch 86cm Undermount Integrated Rangehood - Black (Series 8)
  • Bosch 86cm Undermount Integrated Rangehood - Black (Series 8)
  • Bosch 86cm Undermount Integrated Rangehood - Black (Series 8)
1 3
1 3
Bosch

Bosch 86cm Undermount Integrated Rangehood - Black (Series 8)

Model DLN88PC60A
IPN 868261
$ PRICE MATCH GUARANTEE

We'll match* a local competitor's advertised price on the same product. Contact us for details!

$1,278
Before $0
Now $1,278
PHONE SALES 1300 863 749

Check Availability

Enter your location in the field below to get delivery estimates and stock information for your local store.

Warranty

5 Years Total Warranty on select Bosch Appliances

Bonus warranty on Bosch Series 6 & 8 appliances. 1 Sept - 2 Nov 2026. T&C's apply.
left to claim this offer
Learn More

Promotions For This Product

5 Year Warranty on Bosch Appliances

5 Year Warranty on Bosch Appliances

Buy a selected Series 6 or 8 Bosch appliance and register to receive a 5-year manufacturer’s warranty. T&C's apply.

Offer ends Sun, May 31, 2026

Redeem by Mon, Nov 30, 2026

Learn More
5 Years Total Warranty on select Bosch Appliances

5 Years Total Warranty on select Bosch Appliances

Bonus warranty on Bosch Series 6 & 8 appliances. 1 Sept - 2 Nov 2026. T&C's apply.

Offer ends Mon, Nov 02, 2026

Redeem by Sun, Feb 28, 2027

Learn More
Overview
Delivery & Returns
Payment Options
Reviews

Overview

description

The Bosch 86cm Series 8 Integrated Rangehood combines powerful performance with a sleek, built-in design, keeping your kitchen fresh and free from unwanted odours. With a high airflow capacity of up to 820 m³/h, it effectively removes smoke, steam, and grease for a cleaner cooking space. Electronic push-button controls and a clear digital display make adjusting fan speeds effortless, while its quiet operation—just 61 dB at maximum speed—ensures minimal disruption in your home. Designed to seamlessly integrate into your cabinetry, this rangehood offers both style and functionality, making it a perfect fit for modern kitchens. Whether simmering, frying, or grilling, the Bosch Series 8 rangehood delivers efficient and powerful ventilation with ease.

specifications

  • Brand
    Bosch
  • IPN
    868261
  • Model
    DLN88PC60A
  • Manufacturer's Warranty
    2 Years
  • Size
    86CM
  • Width
    860.0
  • Height
    345.0
  • Depth
    282 mm
  • Colour/Finish
    INTEGRATED (OWN CABINETRY)
  • SIZE (CM)
    86 CM
  • Colour
    Black
  • Installation typology
    Built-in
  • Operating Mode
    Convertible
  • Total power of the motors
    170 W
  • Number of power settings
    3-stages + intensive setting
  • Max. air extraction
    595 m³/h
  • Boost position air extraction
    820 m³/h
  • Sound power at max. speed (2010/30/EC)
    61 dB
  • Sound power boost (2010/30/EC)
    68 dB
  • Max. air recirculation
    570 m³/h
  • Boost position output recirculating
    780 m³/h
  • Sound power at max. speed (recirculation)
    67 dB
  • Sound power boost (recirculation)
    74 dB
  • Grease filter material
    Washable aluminium
  • Energy efficiency rating
    A++
  • Total annual energy consumption
    31.2 kWh/year
  • Included user manuals
    [EN]
  • Minimum distance above an electric cooktop (EU)
    600 mm
  • Minimum distance above a gas cooktop
    650 mm
  • Diameter of air outlet
    120 / 150 mm
  • No-return airflow flap
    Yes
  • Length electrical supply cord
    150.0 cm
  • Handle bar
    Not applicable
  • Appliance height exhaust air max
    345 mm
  • Appliance height exhaust air min
    345 mm
  • Appliance height recirculating max
    345 mm
  • Appliance height recirculating min
    345 mm
  • PerfectAir sensor
    No
  • EcoSilence Drive motor - efficient and extra silent
    Yes
  • Extremely silent appliance
    No
  • Clean filter reminder
    Yes
  • Boost mode
    Yes
  • Delay Shut off modes
    Yes
  • Remote control
    No
  • Type of lamps used
    LED
  • Number of lights
    2
  • Total power of the lamps
    2 W
  • Total luminance
    250 lm
  • Color temperature
    Cold white (4.000 K)
  • Illumination type softlight
    Yes
  • Light colour customisable by Home Connect
    No
  • Ambient light
    No
  • Home Connect
    No
  • Cooktop-based hood control
    No
  • Smart Hood Automatic
    No

features

  • 595 m³/h max air extraction
  • 3-stages + intensive setting
  • EcoSilence Drive
  • Intensive speed setting with reset
  • Seamless integration
  • LED Illumination
  • Push button control
